Digitus 24 Port 10G Ethernet PoE+ Injector, 802.3at, 370 W
GTIN: 4016032430384
10G Ethernet PoE+ Injector Hub, 802.3at 24-port, Power Pins:3/6(+), 1/2(-), 370W
Minimization of the cabling costs for PoE-capable devices
- 24 10G ports with PoE+ support
- 370 watt performance with up to 30 watts per port
- Compatible with the IEEE802.3at standards
- Automatic surge protection
- Supports bandwidth up to 10Gbps
The DIGITUS® DN-95117 is an 24 port 10G PoE+ mid-span hub (PoE injector). It offers 24 input ports for data and 24 output ports which make data and PoE available. Each PoE-port supports connected devices in accordance with the IEEE802.3af and IEEE802.3at PoE standard with 15.4 watts and/or 30 watts, such as PoE access points, PoE IP-telephones or PoE IP cameras, for example. The switch makes available a maximum budget of 370 watts for all ports and maximum budget of 30 watts per port.
| Product Condition | New |
|---|---|
| Manufacturer | Digitus |
| manufacturer code | DN-95117 |
| Ean | 4016032430384 |
| Rack mounting | Yes |
| Modified on | 13-12-2017 |
| Product title | Digitus 24 Port Gigabit Ethernet PoE+ Injector, 802.3af/at, 370 W |
| Long Product Name | Gigabit Ethernet PoE+ Injector Hub, 802.3at, 10G 24-port, Power Pins:3/6(+), 1/2(-), 370W |
| Product specifications | Ports & interfacesBasic switching RJ-45 Ethernet ports quantity* 24 Basic switching RJ-45 Ethernet ports type* Gigabit Ethernet (10/100/1000) Power connector AC-in jack NetworkNetworking standards* IEEE 802.3af 10G support* No Full duplex Yes Auto MDI/MDI-X Yes DesignRack mounting* Yes Form factor 1U Product colour Grey LED indicators Power On/off switch Yes Country of origin China PerformancePlug and Play Yes Mean time between failures (MTBF) 100000 h PowerAC input voltage 100 - 240 V AC input frequency 50 - 60 Hz Input current 4.5 A Power consumption (max) 270 W Surge protection Yes Power protection features Overload, Short circuit Power over Ethernet (PoE)Power over Ethernet (PoE)* Yes Power over Ethernet plus (PoE+) ports quantity 24 Power over Ethernet (PoE)Power over Ethernet (PoE) voltage range 1.2 - 3.6 V Power over Ethernet (PoE) power per port 30 W Total Power over Ethernet (PoE) budget 370 W Operational conditionsOperating temperature (T-T) -10 - 45 °C Storage temperature (T-T) -20 - 70 °C Operating relative humidity (H-H) 0 - 90% Storage relative humidity (H-H) 0 - 95% Weight & dimensionsWidth 345 mm Depth 440 mm Height 45 mm Weight 4.39 kg Packaging dataCables included AC Quick start guide Yes Package type Box Package width 405 mm Package depth 505 mm Package height 95 mm Package volume 19429.9 cm³ Package weight 5.33 kg Logistics dataUK Trade Tariff code 85176200 Harmonized System (HS) code 85176990 Other featuresEthernet interface type Gigabit Ethernet |
| Essential qualities |
|
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Networking standards | IEEE 802.3af |
| 10G support | No |
| Power over Ethernet (PoE) | Yes |
