Lindy 50m 2 Port USB 2.0 Cat. 6 Extender
GTIN: 4002888433860
50m 2 Port USB 2.0 Cat. 6 Extender
This Lindy USB 2.0 Cat.6 Extender can be used to extend the distance between two USB peripheral devices and the host computer by up to 50m. A standard, low cost Cat.6 network cable (not included) is used to bridge the connection between the transmitter and the receiver unit. For best performance and compatibility, we recommend the use of solid core patched cables.
The Extender features bidirectional Power over Cable (PoC) functionality, which provides additional flexibility. This allows power to be supplied alongside data through Cat.6 network cable in a point-to-point connection between the transmitter and receiver, meaning only a single power supply is required at the transmitter or receiver unit.
With robust metal housing and integrated mounting brackets this Extender is the ideal solution for industrial environments.
| Product Condition | New |
|---|---|
| Manufacturer | Lindy |
| manufacturer code | 43386 |
| Ean | 4002888433860 |
| Modified on | 07-12-2023 |
| Product title | Lindy 50m 2 Port USB 2.0 Cat. 6 Extender |
| Long Product Name | 50m 2 Port USB 2.0 Cat. 6 Extender |
| Product specifications | PerformanceType* Network transmitter & receiver Maximum transfer distance* 50 m Data transfer rate 480 Mbit/s Cable types supported Cat5e, Cat6 Chipset NS1021 Plug and Play Yes Ports & interfacesEthernet LAN (RJ-45) ports 2 RJ-45 ports quantity (transmitter) 1 RJ-45 ports quantity (receiver) 1 USB 2.0 ports quantity 3 DC-in jack Yes RJ-45 input ports 1 RJ-45 output ports 1 DesignProduct colour Black Quantity per pack 1 pc(s) PowerInput current 2 A Operational conditionsOperating temperature (T-T) 0 - 50 °C Operational conditionsStorage temperature (T-T) -40 - 125 °C Operating relative humidity (H-H) 0 - 90% Storage relative humidity (H-H) 0 - 90% Weight & dimensionsTransmitter width 6.02 cm Transmitter depth 6.7 cm Transmitter height 2.37 cm Transmitter weight 195 g Receiver width 6.02 cm Receiver depth 6.7 cm Receiver height 2.6 cm Receiver weight 195 g Technical detailsSustainability compliance Yes Sustainability certificates CE, Federal Communications Commission (FCC), REACH, RoHS Compliance certificates CE, Federal Communications Commission (FCC), REACH, RoHS Packaging contentCables included USB Manual Yes AC adapter included Yes |
| Essential qualities |
|
| Type | Network transmitter & receiver |
| Maximum transfer distance | 50 m |
