Aja Video Systems KONA-XPAND-R0 KONA X - Optional Connectivity Expansion for KONA X

AJA KONA Xpand Connectivity Expansion Board for KONA X KONA-XPAND-R0

KONA Xpand is a PCIe card that expands the connectivity of the KONA X video I/O card. It provides bi-level/tri-level video reference (BNC), a 9-pin RS-422 connector for controlling a range of devices, 8 channels of unbalanced AES/EBU audio input and output and LTC timecode in/out on the breakout cable supplied with it. Two channels of balanced analog audio input and output are also available through a user-supplied DB-15 to XLR cable.

Key features

• Bi-level / tri-level video reference (BNC)
• RS-422 machine control (Sony 9-pin protocol)
• 8-channel unbalanced AES/EBU audio I/O on breakout cable
• LTC timecode input and output
• 2-channel balanced analog audio I/O (via user-supplied DB-15 cable)

Compatibility

• AJA KONA X
• AJA KONA XM (audio functions depend on firmware, via AJA SDK)

In the box

• 1 x KONA Xpand card
• 1 x Breakout cable

Specifications

• Dimensions: 108.0 x 15.9 x 98.6 mm, bracket height 127 mm
• Weight: 90.7 g
