AVMatrix DE21-4K-PRO – bi-directional 4K60 HDMI to full NDI encoder/decoder with PoE
GTIN: 6971118003471
Available or to order (see message in the cart)
SKU
AVM-DE21-4K-PRO
€694.18 €569.00
Converts an HDMI signal up to 4K60 to full-bandwidth NDI, or decodes an NDI stream to HDMI: one device for both directions. PoE or USB-C power, compact metal body.
AVMatrix DE21-4K-PRO – bi-directional 4K60 HDMI to full NDI encoder/decoder with PoE
Converts an HDMI signal up to 4K60 to full-bandwidth NDI, or decodes an NDI stream to HDMI: one device for both directions. PoE or USB-C power, compact metal body.
- Video: 1x HDMI input, 1x HDMI output
- Audio: 3.5 mm line in and out
- Network: 1x RJ45 NDI/PoE
- HDMI formats: 4096x2160p and 3840x2160p up to 60, 2560x1080 up to 60, 1080p, 1080i, 720p
- NDI: 1 encode or 1 decode; YCbCr 4:2:2 8-bit; about 250 Mbps at 4K60, 125 Mbps at 1080p60
- Power: PoE or USB-C 5-18 V; consumption 5 W
- Dimensions and weight: 104 x 125.5 x 24.5 mm; 501 g
- Included: 5 V 2 A power adapter, USB cable
- Manufacturer warranty: 3 years
Specifications
- Video: HDMI input x 1, HDMI output x 1
- Audio: 3.5 mm line in and out
- RJ45 port: NDI / PoE x 1
- Power input: USB-C, DC 5-18 V
- HDMI input formats: 4096x2160p and 3840x2160p 60/59.94/50/30/29.97/25/24/23.98; 2560x1080 60 to 23.98; 1920x1080p 60/59.94/50 and 30/29.97/25/24/23.98; 1920x1080i 60/59.94/50; 1280x720p 60 to 23.98
- HDMI output formats: 4096x2160p and 3840x2160p 60/59.94/50/30/29.97/25/24/23.98; 2560x1080 60 to 23.98; 1920x1080p 60/59.94/50 and 30/29.97/25/24/23.98; 1920x1080i 60/59.94/50; 1280x720p 60/59.94/50
- NDI: 1 x NDI encoding or 1 x NDI decoding, YCbCr 4:2:2 8-bit NDI High Bandwidth; typical bit rate 250 Mbps at 4K60, 125 Mbps at 1080p60
- Power: wide voltage 5-18 V; consumption 5 W ±10% (12 V 0.4 A)
- Dimensions: 104 x 125.5 x 24.5 mm
- Weight: 501 g
- Operating temperature: -20 to 60 °C; storage -30 to 70 °C
In the box
- DE21-4K PRO encoder/decoder
- 5 V 2 A power adapter
- USB 2.0 A-C cable
| Product Condition | New |
|---|---|
| Manufacturer | AVMatrix |
| manufacturer code | DE21-4K-PRO |
| Ean | 6971118003471 |
