Blackmagic Design HyperDeck Extreme 8K HDR – 8K HDR broadcast deck with H.265
GTIN: 9338716006209
In stock
SKU
BMD-HYPERD/RSTEX8KHDR
Special Price €5,449.25 €4,466.60 Regular Price €5,923.10
HyperDeck Extreme 8K HDR: 8K broadcast deck with H.265, ProRes and DNx up to 4320p60, 4 12G-SDI inputs, 7" 2000 nit HDR touchscreen, optional M.2 cache and 3D LUTs.
Blackmagic Design HyperDeck Extreme 8K HDR – 8K HDR broadcast deck with H.265
HyperDeck Extreme 8K HDR is the 8K broadcast deck: it combines HyperDeck reliability with H.265 recording, internal cache, 3D LUTs and native 8K and HDR support, with ProRes up to 4320p60.
What the HyperDeck Extreme 8K HDR is for
It is used in 8K and Ultra HD HDR production and post production, as master recorder and player. It has a 7" 1920 x 1200 2000 nit DCI-P3 HDR touchscreen with dedicated play, stop and record buttons, a mini timeline for scrolling through recordings (you can even swipe the image to jog) and a heads up display of timecode, video standard, media status and audio meters. It records to 2 CFast 2.0 cards, USB-C disks and, with an optional M.2 NVMe card, internally or as cache; it supports 3D LUTs, HDR and 10-bit scopes.
Connections, media and power
4 12G-SDI inputs, 5 SDI outputs (12G-SDI A, B, C, D and 3G-SDI monitor), HDMI 2.0 in and out, component and composite video inputs, analog audio on 4 balanced XLR and 2 RCA, 64 SDI audio channels, 10G Ethernet, USB-C 3.1 Gen 2, RS-422 in and out. Internal 100-240V supply and 12V DC on 4-pin XLR, 190 W maximum.
How to choose
For Ultra HD the HyperDeck Extreme 4K HDR is enough; HyperDeck Extreme Control adds traditional deck controls.
At emoc.com this product can be combined with the Blackmagic Design extended warranty.
Technical specifications
Connections
| SDI Video Inputs | 4 |
|---|---|
| SDI Video Outputs | 5 (12G-SDI A, B, C, D and 3G-SDI Monitor Out) |
| SDI Rates | 270Mb, 1.5G, 3G, 6G, 12G. |
| HDMI 2.0 Video Inputs | 1 |
| HDMI 2.0 Video Outputs | 1 |
| Analog Video Inputs | 1 x Component YUV on 3 BNCs, 1 x Composite NTSC/PAL on 1 BNC. |
| Analog Video Outputs | None |
| Analog Audio Inputs | 4 Channels of professional balanced analog audio via XLR connectors and 2 channels of consumer unbalanced via RCA connectors. |
| Built in Speaker | Mono |
| Screen | 7 inch 1920 x 1200. 2000 nit DCI-P3 100% HDR LCD |
| Timecode Connections | 1 x XLR in and 1 x XLR out. |
| Reference Input | Tri-Sync or Black Burst. |
| SDI Audio Inputs | 64 channels embedded audio. |
| SDI Audio Outputs | 64 channels embedded audio. |
| HDMI Audio Inputs | 8 channels embedded audio. |
| HDMI Audio Outputs | 8 channels embedded audio. |
| Remote Control | 1 x RS-422 In, 1 x RS-422 Out. |
| Recorder Configuration | Via user interface or Blackmagic HyperDeck Ethernet Protocol. |
| Ethernet | 10Gb/s |
| External Recording | 1 x USB-C 3.1 Gen 2 (up to 10Gb/s) for external disk recording. |
| Computer Interface | 1 x USB-C for software updates. |
Standards
| SD Video Standards | 525i59.94 NTSC, 625i50 PAL |
|---|---|
| HD Video Standards | 720p50, 720p59.94, 720p60 1080i50, 1080i59.94, 1080i60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 |
| 2K DCI Video Standards | 1080p23.98 DCI, 1080p24 DCI, 1080p25 DCI 1080PsF23.98 DCI, 1080PsF24 DCI, 1080PsF25 DCI |
| Ultra HD Video Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60 |
| 4K DCI Video Standards | 2160p23.98 DCI, 2160p24 DCI, 2160p25 DCI |
| 8K Video Standards | 4320p23.98, 4320p24, 4320p25, 4320p29.97, 4320p30, 4320p50, 4320p59.94, 4320p60 |
| 8K DCI Video Standards | 4320p23.98 DCI, 4320p24 DCI, 4320p25 DCI |
| SDI Compliance | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M Level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1, SMPTE 2082-10 and SMPTE 2084. |
| SDI Metadata Support | HD RP188 and closed captioning CEA-708. HDR Metadata supported on SDI. |
| Audio Sampling | Television standard 24-bit, 48 kHz sample rate. |
| Video Sampling | 4:2:2 YUV |
| Color Precision | 10-bit |
| Color Space | REC 601, REC 709, REC 2020. 33 point 3D LUTS can be applied via the LUTS menu tab. |
| Multi Rate Support | Auto detection of SD, HD, 6G‑SDI, 12G-SDI, 2SI Quad Link 12G-SDI. |
| Copy Protection | HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content. |
Media
| Cache or Internal Recording | Slot for optional M.2 PCIe NVMe card for cache recording or internal recording. Slot supports 60mm 80mm and 110mm cards up to 16Gb/s. |
|---|---|
| Media | 2 x CFast 2.0 card slots and 1 x USB-C 3.1 Gen 2 expansion port for external recording of SD, HD, Ultra HD and 8K. |
| Media Type | CFast card and external USB-C flash drives. |
| Media Format | Can format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems. |
Recording
| Source | Input options include SDI, 4 x SDI (simultaneously records 4 SDI inputs up to 2160p60 as separate files), HDMI, Component, Composite. |
|---|
Supported Codecs
| Video Codecs | ProRes HQ QuickTime, ProRes 422 QuickTime, ProRes LT QuickTime, ProRes Proxy QuickTime for all formats up to 4320p60. Playback only of ProRes 4444 QuickTime up to 2160p60 with auto routing of fill and key over SDI A and B outputs. DNxHD 220x, DNxHD 220x MXF, DNxHD 145, DNxHD 145 MXF, DNxHD 45, DNxHD 45 MXF for 720p and 1080p HD formats up to 60fps. DNxHR HQX, DNxHR HQX MXF, DNxHR SQ, DNxHR SQ MXF, DNxHR LB, DNxHR LB MXF for 2K DCI and 2160p formats up to 60fps. H.265 Medium 4:2:0 10‑bit, H.265 Low 4:2:0 10‑bit for all 2160p formats up to 60 fps. H.264 SDI 4:2:2 10‑bit, H.264 High 4:2:0 8‑bit, H.264 Medium 4:2:0 8‑bit, H.264 Low 4:2:0 8‑bit for all formats up to 1080p60. |
|---|---|
| Audio Codecs | AAC 2 Channels. PCM 2, 4, 8, 16, 32 or 64 Channels. |
Scopes
| Scopes | Waveform, RGB Parade, Vector and Histogram scopes in broadcast quality 10-bit . |
|---|---|
| Viewing Modes | Picture in picture, picture overlay with opacity control. Waveform and RGB parade with standard and HDR graticules and Vector with zoom. |
Computer Capture
| None |
Control
| Built in Control Panel | Integrated capacitive touchscreen LCD with onscreen controls for settings and navigating menus. |
|---|---|
| External Control | RS-422 deck control, SDI start/stop, timecode run. Includes Blackmagic HyperDeck Ethernet Protocol. |
Software
| Software Included | Blackmagic OS Blackmagic HyperDeck Setup |
|---|---|
| Internal Software Upgrade | Loaded at system start, or via Blackmagic HyperDeck Setup using USB port. |
Displays
| Built in LCD for video, audio and timecode monitoring and menu settings. |
Power Requirements
| Power Supply | 1 x Internal 100 - 240V AC. 1 x 4 pin XLR 12V DC IN for external power or battery use. |
|---|---|
| Power Usage | 190W max. |
Accessories
| Optional Accessories | HyperDeck Extreme Control HyperDeck Extreme Rack Kit |
|---|
Physical Installation
| 3 rack units height, half rack width. |
Environmental Specifications
| Operating Temperature | 0° to 40° C (32°to 104° F) |
|---|---|
| Storage Temperature | -20° to 60° C (-4° to 140° F) |
| Relative Humidity | 0% to 90% non-condensing |
What's Included
| HyperDeck Extreme 8K HDR Welcome wallet with QR code for software download |
Warranty
| 1 Year Limited Manufacturer’s Warranty. |
| Product Condition | New |
|---|---|
| Manufacturer | Blackmagic Design |
| manufacturer code | HYPERD/RSTEX8KHDR |
| Ean | 9338716006209 |
| Taric Code | 8521900000 |
| Product specifications | PerformanceVideo compression formats H.265 Audio formats supported AAC, PCM Product colour* Black Analog signal format system NTSC, PAL Video output - digital 5 USB connectivity Yes Ports & interfacesHDMI ports quantity 2 VGA (D-Sub) output ports 1 DVI-I ports quantity 1 NetworkEthernet LAN Yes Ethernet interface type 10 Gigabit Ethernet Ethernet LAN data rates 10000 Mbit/s PowerPower supply type AC AC input voltage 100 - 240 V DisplayBuilt-in display Yes Display type LCD Display diagonal 17.8 cm (7") Display resolution 1920 x 1200 pixels Operational conditionsOperating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 0 - 90% Storage temperature (T-T) -20 - 60 °C Technical detailsWarranty period 1 year(s) |
| Essential qualities |
|
| Product colour | Black |
| Device type | Recorder |
| Maximum resolution | 8K |
| SDI rate | 12G |
| SD support (PAL/NTSC) | Yes |
| Video connection type | SDI, HDMI |
| Recording media | USB-C disk, CFast 2.0 |
| Screen | 7" |
| Network | 10G Ethernet |
| Power | 12 V, AC mains |
| Built-in scopes | Yes |
