Digitus 10" Gigabit 8-Port L2+ Managed PoE+ Switch
GTIN: 4016032464365
10 inch 8-Port Gigabit L2+ Managed PoE+ Switch 80 W
Combines professional-grade network security, VLAN segmentation, and PoE+ power delivery in a compact, quiet 10-inch switch.
- 8× Gigabit PoE+ ports for access points, cameras, VoIP, and IoT (30 W per port)
- L2+ Managed for Professional Network Management
- 80 W total PoE budget
- VLAN (port-based / 802.1Q) for secure segmentation
- QoS for Prioritizing VoIP and Video
- IGMP Snooping for Monitoring & IPTV
- Link Aggregation (LACP) for High Availability and Bandwidth
- Port Security & Access Control
- Management via Web GUI, SNMP, and CLI
- Fanless metal enclosure for 24/7 operation
The DIGITUS® DN-95331 is a professional 8-port Gigabit PoE+ switch in a compact 10-inch form factor designed for high-performance networks in enterprise, security, and building automation applications. Eight PoE+ ports (IEEE 802.3af/at, up to 30 W per port) provide centralized power to IP cameras, Wi-Fi access points, VoIP phones, and IoT components. Unlike basic PoE switches, the DN-95331 offers comprehensive L2+ management features—VLAN, QoS, IGMP snooping, link aggregation, port mirroring, access control, and traffic control—enabling precise segmentation, security, and prioritization. It is managed via a web GUI, SNMP, or CLI. The fanless metal housing ensures silent, continuous operation. The combination of PoE+, Gigabit performance, and L2+ management makes it the ideal foundation for CCTV systems, digital building infrastructure, and connected workplaces.
| Product Condition | New |
|---|---|
| Manufacturer | Digitus |
| manufacturer code | DN-95331 |
| Ean | 4016032464365 |
| Modified on | 25-04-2020 |
| Product title | Digitus 8-Port Gigabit PoE Networkswitch, 10 Zoll, L2 managed, 80 W, af/at |
| Long Product Name | L2 managed Gigabit Ethernet PoE Switch 8-port PoE, 10 inch, 80W PoE budget |
| Product specifications | Management featuresSwitch type* Managed Switch layer L2+ Quality of Service (QoS) support Yes ARP inspection Yes Configuring Location Settings (CLI) Yes Ports & interfacesBasic switching RJ-45 Ethernet ports quantity* 8 Basic switching RJ-45 Ethernet ports type* Gigabit Ethernet (10/100/1000) NetworkNetworking standards* IEEE 802.3at Full duplex Yes IP routing Yes Ethernet LAN data rates 10,100,1000 Mbit/s VLAN support Yes Virtual LAN features Interface-based VLAN, Port-based VLAN, Tagged VLAN Data transmissionForwarding rate 11.9 Mpps MAC address table* 8000 entries Jumbo frames support Yes Jumbo frames 16000 SecurityAccess Control List (ACL) Yes IGMP snooping Yes SSH/SSL support Yes Multicast featuresMulticast support Yes DesignRack mounting* No Stackable* Yes Product colour Black Vandal-proof No DesignSuitable for outdoor use No Country of origin China PowerPower supply included* Yes AC input voltage 100 - 240 V AC input frequency 50 - 60 Hz Power consumption (typical) 96 W Power over Ethernet (PoE)Power over Ethernet (PoE)* Yes Power over Ethernet (PoE) type supported PoE+ Total Power over Ethernet (PoE) budget 80 W Operational conditionsOperating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -10 - 70 °C Operating relative humidity (H-H) 5 - 95% Weight & dimensionsWidth 250 mm Depth 150 mm Height 44 mm Weight 1.14 kg Packaging dataPackage width 240 mm Package depth 70 mm Package volume 5376 cm³ Package weight 1.6 kg Logistics dataUK Trade Tariff code 85176200 Harmonized System (HS) code 85176990 Other featuresEthernet interface type Gigabit Ethernet |
| Essential qualities |
|
| Switch type | Managed |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Networking standards | IEEE 802.3at |
| Rack mounting | No |
| Stackable | Yes |
| Power supply included | Yes |
| Power over Ethernet (PoE) | Yes |
