Digitus mini GBIC (SFP) Module, 1.25 Gbps, 80km

Name: Digitus mini GBIC (SFP) Module, 1.25 Gbps, 80km
Brand: Digitus
SKU: DIG-DN-81002
Price: 38.515401 EUR
Availability: InStock

GTIN: 4016032305675

In stock

SKU

DIG-DN-81002

Be the first to review this product

€38.52 €31.57

Your legal guarantee rights

Manufacturers: Digitus

1.25 Gbps SFP Module, Singlemode LC Duplex Connector, 1550nm, up to 80km

Digitus mini GBIC (SFP) Module, 1.25 Gbps, 80km

Description

More Information

Reviews

The plug and play fiber connection

- The Plug & Play fiber optic link enables quick installation
- Sends data in high quality and additionally provides excellent reliability
- Distance up to 80km at a maximum data rate of 1.25Gbps
- Operating temperature: 0 °C ~ 70 °C

The DIGITUS® mini GBIC (SFP) transceiver modules offer highest quality and reliability. Wether from switch to switch, converter to switch, converter to converter or any else application: The wide product range of DIGITUS® modules makes possible a flexible usage of the fiber technology. The conformity to the MSA (Multi Source Agreement) standard ensures a compatibility to third party manufacturers.

leaflet

More Information
Product Condition	New
Manufacturer	Digitus
manufacturer code	DN-81002
Ean	4016032305675
Modified on	11-03-2012
Product title	Digitus mini GBIC (SFP) Module, 1.25 Gbps, 80km
Long Product Name	1.25 Gbps SFP Module, Singlemode LC Duplex Connector, 1550nm, up to 80km
Product specifications	Performance SFP transceiver type* Fiber optic Maximum data transfer rate* 1250 Mbit/s Interface type* SFP Single-mode fiber (SMF) supported Yes Fiber optic connector LC Fiber cable diameters supported (core/cladding) 9/125 µm SFP transceiver standard LX Maximum transfer distance 80000 m Wavelength 1550 nm Tx power (max) 5 dBmW Rx power (min) -32 dBmW Ethernet interface type Gigabit Ethernet Networking standards IEEE 802.3z Cabling technology 1000Base-LX Digital Diagnostics Monitoring (DDM) No Fiber ports quantity 1 Features Plug and Play Yes Hot-Plug support Yes Country of origin China Brand compatibility MSA Compliant Power Input voltage 3.3 V Packaging data Package width 115 mm Package depth 90 mm Package volume 310.5 cm³ Package weight 35.417 g Logistics data UK Trade Tariff code 85176200 Harmonized System (HS) code 85369010
Essential qualities	Mini GBIC SFP (Small Form Factor Pluggable) module Compatible with the following manuafacturers: Allied Telesis, Allnet, Avaya, CISCO, D-Link, Edimax, FINISAR, FORCE 10, Gigamon Intellinet, KTI Networks, Level One, PLANET, Tenda, TP-Link, TRENDnet, Mikrotik , ENTERASYS, RIVERSTONE , Unifi, Ubiquiti, ZyXEL, ZTE High quality and excellent reliability 1.25 Gbps Maximum Data Rate Compliant to IEEE 802.3z Gigabit Standard Class 1 laser product compliant with EN 60825-1 Easy plug-and-play installation MSA (Multi Source Agreement) compliant Hot pluggable Connector: 1x LC Duplex 1000Base-ZX - For Long Haul Wavelength: 1550nm Transmission Power: Minimum 0 dBm, Maximum 5 dBm Sensitivity Receiving Power: Minimum -32 dBm For a Distance of up to 80km Suitable for 09/125μm Singlemode Fiber Cables Safe fast-locking mechanism 3.3V power supply Operating temperature: 0 °C ~ 70 °C
SFP transceiver type	Fiber optic
Maximum data transfer rate	1250 Mbit/s
Interface type	SFP
