PTZOptics HuddleCamHD Joystick
GTIN: 0840170500111
HuddleCamHD HC-JOY-G4 serial PTZ joystick controller with 3-axis joystick, 7 camera select buttons, VISCA, Pelco-D and Pelco-P over RS-232, RS-422 and RS-485, up to 255 cameras.
HuddleCamHD HC-JOY-G4 Serial PTZ Joystick Controller
Built on the same platform as the PTZOptics SuperJoy, the HuddleCamHD HC-JOY-G4 is a serial PTZ camera controller. Seven camera quick-select buttons sit on the left side, a three-axis joystick gives precise pan, tilt and zoom control, and the on-screen display menu of the camera can be controlled directly. Basic, Basic PTZ and Matrix user modes suit both beginners and experienced operators.
It supports VISCA, Pelco-P and Pelco-D protocols over RS-232, RS-422 and RS-485 wiring. Rubberized, pressure-sensitive multifunction knobs adjust near/far focus, pan/tilt/zoom and preset travel speed, iris, shutter, gain and red/blue gain, with a click on each knob to switch parameters. The redesigned housing is metal.
Key features
- 7 camera quick-select buttons
- 3-axis joystick for pan, tilt and zoom
- Camera OSD menu control
- 10 quick-call presets via alphanumeric buttons
- Iris, shutter, gain, red gain and blue gain knobs
- Focus and PTZ speed knobs, focus lock toggle
- Exposure and white balance mode buttons
- Basic, Basic PTZ and Matrix modes
- Metal housing, rubberized controls
Specifications
- Protocols: VISCA, Pelco-D, Pelco-P
- Interfaces: RS-232, RS-422, RS-485
- Cameras supported: up to 255
- Power: 12 V DC
- Dimensions: 320 x 180 x 109 mm
- Weight: 1.6 kg
- Operating temperature: 0-55 °C
| Product Condition | New |
|---|---|
| Manufacturer | Ptzoptics |
| manufacturer code | HC-JOY-G4 |
| Ean | 0840170500111 |
| Modified on | 05-02-2024 |
| Warranty | 2 years |
| Product title | PTZOptics HuddleCamHD Joystick |
| Long Product Name | The Next Generation of Serial PTZ Control, DC12V, VISCA, PELCO-D, PELCO-P, 255 cameras |
| Product specifications | FeaturesType* Joystick Placement supported* Indoor Product colour* Black Housing material Metal Maximum operating distance 1200 m Maximum number of cameras supported 255 Ports & interfacesConnectivity technology Wired RS-232 ports 1 RS-485 ports 1 PowerPower consumption 2000 mA Weight & dimensionsWidth 320 mm Weight & dimensionsDepth 180 mm Height 109 mm Weight 1.6 kg Packaging dataQuantity per pack 1 pc(s) Packaging contentQuick installation guide Yes Operational conditionsOperating temperature (T-T) 0 - 55 °C Operating relative humidity (H-H) 10 - 90% Technical detailsWarranty period 2 year(s) |
| Essential qualities |
|
| Type | Joystick |
| Placement supported | Indoor |
| Product colour | Black |
