Supermicro AOC-S100G-B2C interface cards/adapter Internal QSFP28
In stock
SKU
SUP-AOC-S100G-B2C-O
Special Price €1,225.34 €1,004.38 Regular Price €1,263.24
Dual-port 100Gb Ethernet adapter with QSFP28 connectors, Broadcom BCM57508 controller and PCIe 4.0 x16 interface, low-profile, for cloud, storage, machine learning and HPC.
Supermicro AOC-S100G-b2C Dual-Port 100GbE QSFP28 Network Adapter
The Supermicro AOC-S100G-b2C is a high-performance dual-port 100Gb/s Ethernet adapter based on the Broadcom NetXtreme E-Series BCM57508 controller, with PCIe 4.0 support and backward compatibility with PCIe 3.0. It is a scalable NIC suited to cloud-scale networking, storage, machine learning, data analytics and HPC. It supports DCB, VXLAN, NVGRE, Geneve and RoCE, while Supermicro asset management and thermal detection add a further level of controller health monitoring.
Key features
- 2 x QSFP28 ports
- Low-profile, short-length standard form factor
- PCIe 4.0 x16, backward compatible with PCIe 3.0 x16
- Broadcom BCM57508 Ethernet controller
- Asset management with thermal sensor
- IEEE 1588 PTP and IEEE 802.1AS
- RDMA over Converged Ethernet (RoCE v1 and v2)
- VXLAN, NVGRE and Geneve; TruFlow and NPAR
- NetQueue, VMQueue and multiple queues
- Jumbo frames up to 9600 bytes
- NC-SI for IPMI support
Specifications
- Ports: 2 x QSFP28 100GbE
- Host interface: PCIe 4.0 x16
- Typical power consumption: 19.51 W
- Dimensions: 167.7 x 68.9 mm
- Operating temperature: 0 to 55 °C
- RoHS compliant
| Product Condition | New |
|---|---|
| Manufacturer | Supermicro |
| manufacturer code | AOC-S100G-B2C-O |
| Product title | Supermicro AOC-S100G-B2C interface cards/adapter Internal QSFP28 |
| Long Product Name | 100Gbps, PCIe 4x, TCP, UDP, IEEE 1588PTP, IEEE 802.1AS |
| Product specifications | Ports & interfacesHost interface* PCIe Output interface* QSFP28 Expansion card form factor Low-profile Expansion card standard PCIe 4.0 DesignInternal* Yes FeaturesBandwidth 100 Gbit/s PowerPower consumption (typical) 19.51 W Operational conditionsOperating temperature (T-T) 0 - 55 °C Storage temperature (T-T) -40 - 70 °C Storage relative humidity (H-H) 10 - 90% Technical detailsSustainability compliance Yes Compliance certificates RoHS Weight & dimensionsWidth 167.7 mm Depth 68.9 mm |
| Essential qualities |
|
| Host interface | PCIe |
| Output interface | QSFP28 |
| Internal | Yes |
