Aja Video Systems DRM2-R0 3RU Mini-Converter Rackmount Frame with 200W Power Supply, Passive Faceplate

AJA DRM2 DRM2-R0 3RU Mini-Converter Rackmount Frame with 200 W Power Supply, Passive Faceplate

The AJA DRM2 DRM2-R0 is a 3RU rackmount frame with 12 mounting slots for any AJA Mini-Converters, which can be installed without removing the frame from the rack. A universal 100-240 V power supply of up to 200 W feeds twelve +5 V DC regulated outputs, hard-wired to the power supply. This version comes with a passive faceplate.

Key features

• 12 mounting slots for any AJA Mini-Converters
• Converters can be installed without removing the frame from the rack
• 200 W power supply with 12 x +5 V DC regulated outputs
• Passive faceplate

Notes

• AJA recommends the active faceplate if power consumption exceeds 100 W with ambient temperature under 30 °C, or exceeds 75 W above 30 °C

Specifications

• Mounting slots: 12, for any AJA Mini-Converters
• Size (w x d x h): 48.26 x 38.1 x 13.34 cm, 3RU
• Weight: 4.2 kg with 12 carriers, hardware, power harness and power cord
• Power: 100-240 V, 50/60 Hz universal input; 12 x +5 V DC regulated outputs; 200 W maximum
• Operating temperature: 0 to 40 °C
• Faceplate weight: 0.4 kg (without fans)
