Aja Video Systems Z-OEM-CRV22-R0 4-Lane PCIe card, 2-in/2-out HD/SD/3G SDI, 2x LTC, Genlock, 2x RS-422, 2x Mixer/Keyer

AJA Corvid 22 Z-OEM-CRV22-R0 4-Lane PCIe Card, 2-in/2-out 3G-SDI

Corvid 22 is an AJA 4-lane PCIe card, in the OEM version, with two channels of 3G/HD/SD-SDI I/O: two inputs and two outputs. It supports formats from SD up to 2K and 1080p 60 (Level A/B), with 16 channels of 24-bit embedded SDI audio on input and output. It provides two LTC timecode channels, genlock to analogue colour black or HD tri-level sync, two RS-422 machine control ports and two mixer/keyers.

Key features

• 2x 3G-SDI inputs, 2x 3G-SDI outputs, SMPTE-259/292/296/424
• 16-channel 24-bit embedded SDI audio in and out, 48 kHz
• 2x LTC timecode
• Genlock: analogue colour black or HD tri-level sync
• 2x RS-422 machine control
• 2x mixer/keyer

Specifications

• Formats: 2K 2048x1080p/PsF 23.98-25; 1080p up to 60 (A/B); 1080PsF; 1080i; 720p; 625i; 525i
• Bus: 4-lane PCIe
• Size: 18 x 166.9 x 98.1 mm
• Weight: 0.3 kg
• Power: 12 W typical, 15 W max
• Operating temperature: 0 to 40 °C
