DataVideo TLM-170V computer monitor 43.2 cm (17") 1920 x 1080 pixels LCD Black
GTIN: 0672255008324
In stock
SKU
DAT-2100-0193
Special Price €1,842.24 €1,510.03 Regular Price €1,939.19
17.3" Full HD desktop monitor with 1920 x 1080 panel, 3G/HD/SD-SDI and HDMI inputs with loop-through, SDI/HDMI cross conversion, waveform, vectorscope and tally light.
Datavideo TLM-170V 17.3" Full HD Desktop Monitor
The Datavideo TLM-170V is a 17.3" Full HD desktop monitor supporting 3G/HD/SD signals on a 1920 x 1080 panel. It has one 3G/HD/SD-SDI and two HDMI inputs, plus one SDI and one HDMI loop-through output, and can cross convert between SDI and HDMI, so it fits easily into different video production workflows. Built-in functions include column (YRGB peak), time code, waveform, vectorscope and audio level meter, peaking, zoom, pixel to pixel, underscan and check field. A tally light is included for live production.
Key features
- Inputs: 1 x 3G/HD/SD-SDI, 2 x HDMI; loop-through: 1 x SDI, 1 x HDMI
- SDI/HDMI cross conversion
- Column (YRGB peak), time code, waveform, vectorscope, audio level meter, peaking, zoom, pixel to pixel, underscan, check field
- Tally light
Specifications
- Display: 17.3" LCD, LED backlight, 1920 x 1080
- Brightness: 300 cd/m²
- Contrast ratio: 700:1
- Video modes: 480i, 576i, 720p, 1080i, 1080p
- Speakers: 2; headphone output: 1
- Power consumption: 21.9 W
- Operating temperature: 0-40 °C
- Dimensions (with stand): 403 x 305 x 37 mm
- Weight (with stand): 4.5 kg
| Product Condition | New |
|---|---|
| Manufacturer | Datavideo |
| manufacturer code | 2100-0193 |
| Ean | 0672255008324 |
| Modified on | 22-10-2022 |
| Product title | DataVideo TLM-170V computer monitor 43.2 cm (17") 1920 x 1080 pixels LCD Black |
| Long Product Name | 17.3" LED Backlit, 1920x1080, 300cd/m², 700:1, 2x 3G/HD/SD-SDI, 2x HDMI, 2x Speaker, 1x Headphone Jack, 403 x 305 x 37 mm, 4.5 kg |
| Product specifications | DisplayDisplay diagonal* 43.2 cm (17") Display resolution* 1920 x 1080 pixels Native aspect ratio* 16:9 Display technology* LCD LED backlight Yes Touchscreen* No Display brightness (peak) 300 cd/m² Screen shape* Flat Supported graphics resolutions 1920 x 1080 (HD 1080) Supported video modes 480i, 576i, 720p, 1080i, 1080p Aspect ratio 4:3, 16:9 Contrast ratio (typical)* 700:1 Maximum refresh rate* 60 Hz Viewing angle, horizontal 89° Viewing angle, vertical 89° High Dynamic Range (HDR) supported Yes PerformanceNVIDIA G-SYNC* No AMD FreeSync* No MultimediaBuilt-in speaker(s)* Yes Built-in camera* No Number of speakers 2 DesignMarket positioning* Business Product colour* Black Ports & interfacesBuilt-in USB hub* No HDMI* Yes HDMI ports quantity 2 12G-SDI ports quantity 2 Audio input Yes Audio output Yes Headphone out* Yes Headphone outputs 1 PowerPower consumption (typical)* 21.9 W Operational conditionsOperating temperature (T-T) 0 - 40 °C Packaging contentStand included Yes Cables included DC Weight & dimensionsWidth (with stand) 305 mm Depth (with stand) 37 mm Height (with stand) 403 mm Weight (with stand) 4.5 kg |
| Essential qualities |
|
| Display diagonal | 43.2 cm (17") |
| Display resolution | 1920 x 1080 pixels |
| Native aspect ratio | 16:9 |
| Display technology | LCD |
| Touchscreen | No |
| Screen shape | Flat |
| Contrast ratio (typical) | 700:1 |
| Maximum refresh rate | 60 Hz |
| NVIDIA G-SYNC | No |
| AMD FreeSync | No |
| Built-in speaker(s) | Yes |
| Built-in camera | No |
| Market positioning | Business |
| Product colour | Black |
| Built-in USB hub | No |
| HDMI | Yes |
| Headphone out | Yes |
| Power consumption (typical) | 21.9 W |
