Supermicro CSE-947HE1C-R2K05JBOD computer case Rack Black 2000 W
In stock
SKU
SUP-CSE-947HE1C-R2K05JBOD
Special Price €10,924.90 €8,954.84 Regular Price €11,874.89
4U top-loading single-path JBOD storage enclosure for 90 x 3.5"/2.5" hot-swap SATA 6 Gb/s / SAS3 12 Gb/s drives, 6 x SAS3 I/O ports, IPMI and redundant 2000 W Titanium power supplies.
Supermicro CSE-947HE1C-R2K05JBOD 4U 90-Bay Top-Load JBOD 2000 W Redundant
The Supermicro CSE-947HE1C-R2K05JBOD is a 4U rackmount top-load JBOD storage enclosure, single path, with a single canister controller on a field-serviceable tray. It holds 90 hot-swap 3.5"/2.5" top-loading SATA 6 Gb/s or SAS3 12 Gb/s drives and offers six SAS3 I/O ports (Mini-SAS HD SFF-8644). Management is via a dedicated IPMI RJ45 port with Redfish out-of-band support and SCSI Enclosure Services SES-4. The hot-swappable tool-less modular design eases service, and power comes from redundant 2000 W Titanium supplies.
Key features
- Single-path storage enclosure, single canister controller with field-serviceable tray
- 90 x 3.5"/2.5" top-loading hot-swap SATA 6 Gb/s / SAS3 12 Gb/s drives
- 6 x SAS3 I/O ports (Mini-SAS HD SFF-8644)
- Dedicated IPMI RJ45 management port, Redfish out-of-band management
- SCSI Enclosure Services SES-4
- Hot-swappable tool-less modular design
- Redundant 2000 W Titanium power supplies
Specifications
- Form factor: 4U rackmount
- Dimensions: 447 x 1099 x 177 mm (W x D x H)
- Weight: 59 kg
- Operating temperature: 5 to 35 °C
- Colour: black
| Product Condition | New |
|---|---|
| Manufacturer | Supermicro |
| manufacturer code | CSE-947HE1C-R2K05JBOD |
| Form factor | Rack |
| Type | Server |
| Product colour | Black |
| Product title | Supermicro CSE-947HE1C-R2K05JBOD computer case Rack Black 2000 W |
| Long Product Name | 4U Rackmount Top-Load JBOD Storage Enclosure |
| Product specifications | DesignForm factor* Rack Type* Server Product colour* Black Number of storage drives supported 90 Rack mounting Yes Rack capacity 4U Reset button Yes On/off button Yes LED indicators Yes Certification BSMI
CCC
CE/EMC
FCC class A
TUV/CB
UL/CUL Power supplyPower supply included* Yes Power supply 2000 W CoolingNumber of front fans supported (max) 6 Front fans diameters supported 80 mm StorageSupported HDD sizes* 2.5,3.5" Hot-swap Yes Operational conditionsOperating temperature (T-T) 5 - 35 °C Storage temperature (T-T) -40 - 70 °C Operating relative humidity (H-H) 8 - 90% Storage relative humidity (H-H) 5 - 95% Weight & dimensionsWidth 447 mm Depth 1099 mm Height 177 mm Weight 59 kg Packaging dataPackage weight 102.1 kg |
| Essential qualities |
|
| Power supply included | Yes |
| Supported HDD sizes | 2.5,3.5" |
