Supermicro CSE-947HE2C-R2K05JBOD computer case Rack Black, Grey 2000 W
GTIN: 0672042431953
4U top-loading dual-path JBOD storage enclosure for high availability, 90 x 3.5"/2.5" hot-swap SAS3 12 Gb/s drives, two redundant canister controllers and redundant 2000 W Titanium power supplies.
Supermicro CSE-947HE2C-R2K05JBOD 4U 90-Bay Dual-Path Top-Load JBOD 2000 W Redundant
The Supermicro CSE-947HE2C-R2K05JBOD is a 4U rackmount top-load JBOD storage enclosure with a dual-path design for high-availability applications. It supports two canister controllers in a 1+1 redundant configuration and holds 90 hot-swap 3.5"/2.5" top-loading SAS3 12 Gb/s drives, with six SAS3 I/O ports (Mini-SAS HD SFF-8644) per node. Management is via a dedicated IPMI RJ45 port with Redfish out-of-band support and SES-4. The hot-swappable tool-less modular design eases service, and power comes from redundant 2000 W Titanium supplies.
Key features
- Dual-path storage enclosure for high-availability applications
- 2 canister controllers, 1+1 redundant
- 90 x 3.5"/2.5" top-loading hot-swap SAS3 12 Gb/s drives
- 6 x SAS3 I/O ports (Mini-SAS HD SFF-8644) per node
- Dedicated IPMI RJ45 port, Redfish out-of-band management, SES-4
- Hot-swappable tool-less modular design
- Redundant 2000 W Titanium power supplies; 6 x 80 mm fans
Specifications
- Form factor: 4U rackmount
- Dimensions: 447 x 1099 x 177 mm (W x D x H)
- Weight: 59 kg
- Operating temperature: 5 to 35 °C
| Product Condition | New |
|---|---|
| Manufacturer | Supermicro |
| manufacturer code | CSE-947HE2C-R2K05JBOD |
| Ean | 0672042431953 |
| Form factor | Rack |
| Type | Server |
| Product colour | Black, Grey |
| Product title | Supermicro CSE-947HE2C-R2K05JBOD computer case Rack Black, Grey 2000 W |
| Long Product Name | SuperChassis 4U Rackmount Top-Load JBOD Storage Enclosure |
| Product specifications | DesignForm factor* Rack Type* Server Product colour* Black, Grey Number of storage drives supported 90 Rack mounting Yes Rack capacity 4U On/off button Yes Certification BSMI
CCC
CE/EMC
FCC class A
TUV/CB
UL/CUL Power supplyPower supply included* Yes Power supply 2000 W CoolingRear fans installed 6x 80 mm Number of rear fans supported (max) 6 Rear fans diameters supported 80 mm StorageSupported HDD sizes* 2.5,3.5" Operational conditionsOperating temperature (T-T) 5 - 35 °C Storage temperature (T-T) -40 - 70 °C Operating relative humidity (H-H) 8 - 90% Storage relative humidity (H-H) 5 - 95% Weight & dimensionsWidth 447 mm Depth 1099 mm Height 177 mm Weight 59 kg Packaging dataPackage width 910 mm Package depth 1345 mm Package height 755 mm Package weight 102.1 kg |
| Essential qualities |
|
| Power supply included | Yes |
| Supported HDD sizes | 2.5,3.5" |
