DeLOCK PCI Express x8 Card with 2 x USB 20 Gbps USB Type-C female and 2 x USB 10 Gbps Type-A female - Quad Channel
GTIN: 4043619900978
PCI Express x8 Card with 2 x USB 20 Gbps USB Type-C female and 2 x USB 10 Gbps Type-A female - Quad Channel
The PCI Express card by Delock expands the PC by four external USB 3.2 ports, two USB-C™ and two USB Type-A ports. Different USB devices, such as docking stations, card readers, external enclosures etc., can be connected to the card.
Quad Channel
The card has four ASM3242 chipsets, a separate chipset for each USB connector. This ensures the high data transfer rate of 20 Gbps on the USB Type-C™ ports and 10 Gbps on the USB Type-A ports when used at the same time.
Power supply
The PCIe card can be supplied with power via the PCIe connector. If this is not sufficient, the card has a 4 pin power connector. At the USB Type-C™ ports the maximum output is 5 V / 3 A and at the Type-A ports 5 V / 0.9 A, all ports together have an output of maximum 7.8 A.
| Product Condition | New |
|---|---|
| Manufacturer | Delock |
| manufacturer code | 90097 |
| Ean | 4043619900978 |
| Taric Code | 84718000 |
| Internal | Yes |
| Product title | DeLOCK PCI Express x8 Card with 2 x USB 20 Gbps USB Type-C female and 2 x USB 10 Gbps Type-A female - Quad Channel |
| Long Product Name | PCI Express x8 Card with 2 x USB 20 Gbps USB Type-C female and 2 x USB 10 Gbps Type-A female - Quad Channel |
| Product specifications | Ports & interfacesHost interface* PCIe Host interface gender Male Output interface* USB 3.2 Gen 2 (3.1 Gen 2), USB Type-C Expansion card standard PCI 3.0 USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2 USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 2 DesignInternal* Yes Easy to install Yes Country of origin China FeaturesBuilt-in processor Yes Chipset Pericom PI7C9X3G816GP Data transfer rate (max) 20 Gbit/s UASP support Yes PowerOutput voltage 5 V Output current 3 A System requirementsWindows operating systems supported Windows 10, Windows 11, Windows 8.1 Linux operating systems supported Linux Kernel 5.15 Technical detailsSustainability compliance Yes Compliance certificates CE Packaging dataQuantity per pack 1 pc(s) Manual Yes Package type Box |
| Essential qualities |
|
| Host interface | PCIe |
| Output interface | USB 3.2 Gen 2 (3.1 Gen 2), USB Type-C |
