Digitus All-in-one UPS, 800VA/480W, LED
GTIN: 4016032456582
All-in-One UPS, 800VA/480W, LED 12V/9Ah x1, 4x CEE 7/7,3x IEC C13, USB, RJ45
All-in-one: Reliable protection against data and power failure, surge damage for your connected devices
- Microprocessor-controlled control unit guarantees high reliability
- Line-interactive with AVR boost and buck - Automatic voltage regulation
- Space-saving: also suitable for wall mounting
- Integrated charger for mobile devices (USB)
- Auto-restart: Automatic switch-off function after battery discharge, automatic switch-on as soon as the mains connection is supplied with power again
- Auto-charging: Automatic charging function when switched off
The Line-Interactive UPS models offer protection against power failure, overvoltage damage, data loss and much more. User-friendly handling, a high level of performance and safety thanks to the integrated microprocessor control unit characterize the Line-Interactive series. Protect yourself against data loss and damage to your devices in the home and office. Protect your devices with the AVR function, which automatically provides the correct voltage and prevents overvoltage and undervoltage. Further safety features such as overload / discharge and overcharge protection as well as cold start and energy saving functions round off this UPS series. Data loss and damage are a thing of the past with this UPS system.
| Product Condition | New |
|---|---|
| Manufacturer | Digitus |
| manufacturer code | DN-170111 |
| Ean | 4016032456582 |
| Form factor | Compact |
| Product colour | Black |
| Modified on | 25-08-2019 |
| Product title | Digitus All-in-One UPS, 800VA/480W, LED |
| Long Product Name | All-in-One UPS, 800VA/480W, LED 12V/9Ah x1, 4x CEE 7/7,3x IEC C13, USB, RJ45 |
| Product specifications | FeaturesUPS topology* Line-Interactive Output power capacity* 0.6 kVA Output power* 480 W Waveform* Sine Input operation voltage (min)* 162 V Input operation voltage (max)* 290 V Input frequency* 50/60 Hz Output voltage regulation 10% Automatic Voltage Regulation (AVR) Yes Noise level 40 dB Surge protection Yes Surge protection features Network Power protection features Overcharge, Overdischarge, Overload Audible alarm(s) Yes Audible alarm modes Alarm when on battery, Fault, Low battery alarm, Overload alarm Auto-restart Yes Auto power off Yes Country of origin China Ports & interfacesAC outlet types C13 coupler Power plug C14 coupler AC outlets quantity 7 AC outlet(s) USB port Yes USB 2.0 ports quantity 2 Ethernet LAN (RJ-45) ports 2 BatteryBattery capacity 9 Ah Battery voltage 12 V BatteryNumber of batteries supported 1 Battery recharge time 8 h Charging current 2 A DesignForm factor* Compact Product colour* Black LED indicators Yes Operational conditionsOperating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 0 - 90% Weight & dimensionsWidth 202 mm Depth 285 mm Height 90 mm Weight 5.2 kg Package width 238 mm Package depth 352 mm Package weight 3.05 kg Packaging dataManual Yes Package volume 10555.8 cm³ Logistics dataUK Trade Tariff code 85044085 Harmonized System (HS) code 85078000 Other featuresInput connection type 4 x CEE 7/7, 3 x IEC C13 |
| Essential qualities |
|
| UPS topology | Line-Interactive |
| Output power capacity | 0.8 kVA |
| Output power | 480 W |
| Input operation voltage (min) | 162 V |
| Input operation voltage (max) | 290 V |
| Waveform | Sine |
| Input frequency | 50/60 Hz |
