Lindy 100m Cat.6 HDMI 4K60, IR and RS-232 HDBaseT Extender, Receiver
GTIN: 4002888382076
Lindy 100m Cat.6 HDMI 4K60, IR and RS-232 HDBaseT Extender, Receiver, 3840 x 2160 pixels, AV receiver, 150 m, Wired, Black, HDCP
The Lindy C6 HDBaseT HDMI 4K60 and IR Extender, Receiver is one part of a high performance solution for extending HDMI signals over long distances via Cat.6 network cable. By combining this receiver unit with a compatible Lindy HDBaseT transmitter, splitter or matrix, this solution ensures reliable transmission up to 150m.
The following distance and resolution combinations are possible when using high quality Cat.6 U/UTP or F/UTP cable:
150m (492.12ft) - 1280x720@60Hz via Long Reach Mode 100m (328.08ft) - 3840x2160@30Hz 4:4:4 8bit 70m (229.66ft) - 3840x2160@60Hz 4:4:4 8bit
Supporting resolutions up to 4K UHD 3840x2160@60Hz, video can be viewed in stunning clarity, while additional support for HDR (High Dynamic Range) allows content to be displayed with enhanced brightness, greater contrasts of blacks and whites and a much wider colour gamut. This provides a reliable solution for creating eye-catching digital signage in retail, immersive displays at events or engaging setups in larger conference rooms or lectures halls. Analogue audio can be easily extracted via 3.5mm port for connecting speakers or amplifiers, to provide dual channel immersive audio to compliment the video content.
PoC (Power over Cable) functionality provides additional flexibility. This allows power to be supplied alongside data through Cat.6 network cable in a point to point connection between the transmitter and receiver, meaning only a single power supply is required at the transmitter unit. Ideal when power outlets are limited at the receiver end of the installation.
Featuring bi-directional IR ports at both sides of the setup, the source equipment can be easily controlled from the display side, and the display can also be controlled from the HDMI source side. Combined with CEC control, which allows commands from one main remote, this extension system allows for complete and simple control for the user.
Terminal blocks allows for pass-through of RS-232 commands when integrated into control systems.
HDBaset is a globally recognised standard for high quality distribution of AV content and other technologies, including power and control, over longer distances via low cost Cat.6 or above cable.
HDBaseT and the HDBaseT Alliance logo are trademarks of the HDBaseT Alliance.
Please Note: Due to the methods of compression with this product, it is recommended this item is only used for a point to point connection with 38206.
| Product Condition | New |
|---|---|
| Manufacturer | Lindy |
| manufacturer code | 38207 |
| Ean | 4002888382076 |
| Modified on | 19-04-2020 |
| Product title | Lindy 100m Cat.6 HDMI 4K60, IR and RS-232 HDBaseT Extender, Receiver |
| Long Product Name | 100m Cat.6 HDMI 4K60, IR and RS-232 HDBaseT Extender, Receiver |
| Product specifications | FeaturesType* AV receiver Maximum resolution* 3840 x 2160 pixels Cable types supported Cat6 Maximum transfer distance 150 m Chipset VS100 Maximum refresh rate 60 Hz Bidirectional Yes CEC pass-through Yes Supported graphics resolutions 1280 x 720 (HD 720), 3840 x 2160 Bandwidth 18 Gbit/s HDCP Yes Material Metal HDCP version 2.2 Product colour Black HDBaseT certified Yes Ports & interfacesConnectivity technology* Wired RJ-45 input ports 1 HDBaseT port Yes Number of HDMI outputs 1 USB ports quantity 1 Audio input 1 Remote (IR) input 1 Remote (IR) output 1 Ports & interfacesDC-in jack Yes PowerOperating voltage 24 V Input current 1 A Operational conditionsOperating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -20 - 60 °C Operating relative humidity (H-H) 20 - 90% Weight & dimensionsWidth 140 mm Depth 65 mm Height 18 mm Weight 315 g Packaging dataQuantity per pack 1 pc(s) Package width 220 mm Package depth 70 mm Package height 130 mm Package weight 847 g Packaging contentCables included IR Manual Yes IR receiver included Yes |
