Lindy 300m Cat.6 4 Port VGA Splitter Extender Transmitter
GTIN: 4002888354035
300m Cat.6 4 Port VGA Splitter Extender Transmitter
VGA splitter extenders distribute analogue video content across longer distances into multiple locations, using standard network cabling.
The Lindy 300m Cat.6 4 Port VGA Splitter is a high-quality solution for extending 4 separate analogue VGA signals over long distances using standard network cables when combined with the compatible receiver unit (35404). Supporting resolutions up to 1920x1080, this extender splitter provides high quality video for up to 4 separate distribution zones, such as classrooms or in security facilities. A 3.5mm female port ensures source devices or embedded audio can be added within the connection.
The VGA loop-out allows for the connection of a local display, great for monitoring and control of the setup. Dual mono audio extraction also provides the possibility of connecting speakers to the local setup.
The transmitter has a robust metal housing with mounting brackets, providing additional protection against accidental damage, ideal for use in industrial installations.
| Product Condition | New |
|---|---|
| Manufacturer | Lindy |
| manufacturer code | 35403 |
| Ean | 4002888354035 |
| Modified on | 10-03-2021 |
| Product title | Lindy 300m Cat.6 4 Port VGA Splitter Extender Transmitter |
| Long Product Name | 300m Cat.6 4 Port VGA Splitter Extender Transmitter |
| Product specifications | FeaturesType* AV transmitter Maximum resolution* 1920 x 1080 pixels Cable types supported Cat5e, Cat6 Maximum transfer distance 300 m Chipset EL4543IUZ Supported graphics resolutions 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1920 x 1080 (HD 1080) Bandwidth 350 MHz Material Metal Product colour Black Certification CE, FCC, RoHS, REACH Ports & interfacesConnectivity technology* Wired RJ-45 output ports 4 VGA (D-Sub) input ports 1 VGA (D-Sub) output ports 1 Audio input 1 Audio output 1 DC-in jack Yes PowerOperating voltage 12 V Input current 1.2 A Operational conditionsOperating temperature (T-T) 0 - 50 °C Storage temperature (T-T) -20 - 70 °C Operating relative humidity (H-H) 20 - 80% Weight & dimensionsWidth 135.4 mm Depth 73 mm Height 31 mm Weight 484 g Packaging dataQuantity per pack 1 pc(s) Package width 177 mm Package depth 75 mm Package height 110 mm Package weight 547 g |
| Essential qualities |
|
| Type | AV transmitter |
| Maximum resolution | 1920 x 1080 pixels |
| Connectivity technology | Wired |
